Yanmar ViO17-1 True Zero Tail Swing Mini Excavator – 10.1 kW (13.5 HP)
ViO17-1
Yanmar ViO17-1 Mini Excavator | 13.5 HP Zero Tail Swing
The Yanmar ViO17-1 is a true zero tail swing mini excavator designed for professionals working in confined and demanding job sites. Powered by a 10.1 kW (13.5 HP) Yanmar 3TNV70-XBV diesel engine, the ViO17-1 combines compact maneuverability, a sliding variable undercarriage and strong digging performance in a machine weighing approximately 1,785 kg with rubber tracks.
With its true zero tail swing design, the ViO17-1 is particularly suited to construction and excavation work where space is limited. The machine is available in Saudi Arabia through Abdullah Hashim Company (AHCL) – Auto & Equipment Division, the exclusive dealer of Yanmar products in Saudi Arabia.
Key Features & Benefits
True Zero Tail Swing
The ViO17-1 features Yanmar's true zero tail swing concept. Its upper frame does not extend beyond the track width, allowing operators to work more safely in tighter spaces.
This makes the machine well suited for confined construction sites, narrow job sites and excavation work close to walls or other obstacles.
Sliding Variable Undercarriage
The undercarriage retracts to 950 mm to help the excavator pass through narrow passages and extends to 1,280 mm for increased stability during operation.
Powerful Yanmar Diesel Engine
The ViO17-1 is equipped with a vertical 3-cylinder water-cooled diesel engine, model 3TNV70-XBV, producing a gross rated output of 10.1 kW (13.5 HP) at 2,200 rpm.
Strong Digging Performance
The machine provides a maximum bucket digging force of 15.2 kN (3,418 lbs.) and maximum arm digging force of 8.6 kN (1,933 lbs.).
Excellent Performance in a Compact Package
The ViO17-1 is designed to combine compact dimensions with professional-level performance, making it suitable for jobs where access and maneuverability are important. The brochure describes the machine as providing "top performance and reliability for professionals."
Enhanced Hydraulic Performance
Yanmar's ViPPS hydraulic system uses a progressive three-pump system to support smooth and simultaneous operation of machine functions, including operation while traveling.
Upgraded Oil Cooler
The upgraded oil cooler incorporates additional fins to enhance cooling performance, particularly for hydraulic oil. According to the catalogue, this supports heat balance in different weather conditions and can help prolong the lifetime of internal components.
Protected Hydraulic Components
The boom cylinder hose is protected against damage caused by dirt and sand, while spring steel guards protect the cylinders and help reduce potential machine downtime.
LED Working Light
The built-in LED working light provides brighter illumination for working safely and accurately in dark spaces.
Walk-Through Operator Access
The walk-through design allows the operator to get on and off the machine from both sides. This is particularly useful when operating directly beside a wall or other obstruction.
ROPS & FOPS Protection
The four-pole canopy incorporates ROPS and FOPS protective structures that meet ISO standards. ROPS is designed to protect the operator in the event of a rollover, while FOPS provides protection against falling objects.
Easy Maintenance
The ViO17-1 provides convenient access to key components. The battery, starter motor and generator can be accessed beneath the operator seat, while wide-opening covers provide access to the engine, air cleaner, hydraulic components, return filter, radiator and fuel filler.
Yanmar ViO17-1 True Zero Tail Swing Mini Excavator
The Yanmar ViO17-1 is a compact mini excavator developed for professional applications where maneuverability, reliability and performance are important. Its true zero tail swing design allows the upper frame to remain within the track width, helping the operator work more effectively in confined spaces and close to obstacles.
Powered by a Yanmar 3TNV70-XBV vertical 3-cylinder water-cooled diesel engine, the ViO17-1 delivers a gross rated output of 10.1 kW (13.5 HP) at 2,200 rpm. It provides a maximum bucket digging force of 15.2 kN and maximum arm digging force of 8.6 kN.
The sliding variable undercarriage is one of the machine's key features. It retracts from 1,280 mm to 950 mm, allowing the excavator to pass through narrower access points, and can then be extended to 1,280 mm to provide greater stability during operation.
The ViO17-1 is also equipped with a ViPPS hydraulic system, which uses Yanmar's progressive three-pump system to support smooth simultaneous machine movements.
For demanding working conditions, the machine incorporates an upgraded oil cooler designed to improve hydraulic oil cooling and maintain heat balance in different weather conditions. The catalogue also highlights protected boom cylinder hoses and spring steel cylinder guards to help protect components from dirt, sand and potential damage.
The ViO17-1 is suitable for Saudi Arabian environments, making it a practical compact excavator solution for construction, excavation and other equipment applications across the Kingdom.
Its compact dimensions and true zero tail swing configuration can be particularly valuable for Saudi construction projects, urban development, utility work and other job sites where available operating space is restricted.
Yanmar ViO17-1 in Saudi Arabia
The Yanmar ViO17-1 is available in Saudi Arabia through Abdullah Hashim Company (AHCL) – Auto & Equipment Division, the exclusive dealer of Yanmar products in Saudi Arabia.
Abdullah Hashim Company has been a leading provider of advanced industrial equipment and solutions since 1940, representing premium international brands and serving customers across the Kingdom.
Through its Auto & Equipment Division, AHCL provides Yanmar equipment and solutions to customers across Saudi Arabia.
AHCL Auto & Equipment Division Branches
Yanmar equipment and related solutions are supported through AHCL's Auto & Equipment Division network across Jeddah, Riyadh, Dammam, Tabuk, Buraidah, Jubail, Madinah, Hail, Al Hassa, Jizan, and Al Kharj. Customers looking for a Yanmar mini excavator in Saudi Arabia can contact the AHCL Auto & Equipment Division for product availability and equipment support.
Applications
Construction Projects
The ViO17-1's compact dimensions and digging performance make it suitable for a range of construction and excavation applications.
Confined-Space Excavation
The true zero tail swing design allows the machine to operate effectively in tight spaces where conventional tail swing can be restrictive.
Narrow Access Sites
The variable undercarriage can retract to 950 mm, helping the machine pass through narrow passages before extending to 1,280 mm for greater operating stability.
Earth Cleaning
The minimal distance between the bucket and blade makes it easier to push and collect soil during earth-cleaning applications.
Demolition Applications
The standard PTO hydraulic line is designed to provide performance for demolition applications, while Yanmar hydraulic breakers are available as attachments.
Urban and Restricted Job Sites in Saudi Arabia
The machine's true zero tail swing configuration makes it particularly relevant to projects where space is limited, including urban construction projects and restricted job sites across Saudi Arabia.
Why Choose the Yanmar ViO17-1?
- True zero tail swing design
- 10.1 kW (13.5 HP) Yanmar diesel engine
- Sliding variable undercarriage
- 950–1,280 mm track width
- 1,785 kg operating weight with rubber tracks
- 15.2 kN maximum bucket digging force
- 8.6 kN maximum arm digging force
- ViPPS hydraulic system
- Upgraded oil cooler
- Protected boom cylinder hose
- Spring steel cylinder guards
- LED working light
- ROPS & FOPS canopy
- Walk-through operator access
- Easy maintenance access
- PTO hydraulic line
- Suitable for Saudi Arabian environments
- Available through the exclusive Yanmar dealer in Saudi Arabia
Frequently Asked Questions
What is the Yanmar ViO17-1?
The Yanmar ViO17-1 is a true zero tail swing mini excavator designed for professional applications and tight job sites. It is powered by a 10.1 kW (13.5 HP) Yanmar diesel engine.
What is the engine power of the Yanmar ViO17-1?
The ViO17-1 uses a Yanmar 3TNV70-XBV vertical 3-cylinder water-cooled diesel engine producing 10.1 kW (13.5 HP) at 2,200 rpm.
What is a true zero tail swing excavator?
A true zero tail swing excavator is designed so that its upper frame does not extend beyond the track width. On the ViO17-1, this allows the operator to work more effectively in tight spaces.
How wide is the Yanmar ViO17-1?
The sliding variable undercarriage retracts to 950 mm and extends to 1,280 mm.
What is the operating weight of the ViO17-1?
The operating weight is 1,785 kg with rubber tracks and 1,870 kg with steel tracks.
What is the maximum digging depth of the ViO17-1?
The catalogue lists a maximum digging depth of 2,210 mm, with an alternative figure of 2,310 mm shown in the specifications.
What is the maximum digging force?
The maximum bucket digging force is 15.2 kN (3,418 lbs.), while the maximum arm digging force is 8.6 kN (1,933 lbs.).
Is the Yanmar ViO17-1 suitable for Saudi Arabia?
The ViO17-1 is suitable for Saudi Arabian environments and can be used for construction, excavation and other applications across the Kingdom. Its compact true zero tail swing design is particularly useful for restricted and urban job sites.
Who is the Yanmar dealer in Saudi Arabia?
Abdullah Hashim Company (AHCL) – Auto & Equipment Division is the exclusive dealer of Yanmar products in Saudi Arabia.
Where can I find AHCL Auto & Equipment Division?
AHCL Auto & Equipment Division has branches in Jeddah, Riyadh, Dammam, Tabuk, Buraidah, Jubail, Madinah, Hail, Al Hassa, Jizan and Al Kharj.
